Module SMS-050-P10-1000 - Bosch Rexroth R02681E020

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Module SMS-050-P10-1000 - Bosch Rexroth R02681E020

Bosch Rexroth ✓ Original product Brand new Made in Germany

Module SMS-050-P10-1000 by Bosch Rexroth, material number R02681E020. Size SMS-050.

Net
€1,757.27
excl. VAT
Item BRR-R02681E020
Manufacturer no. R02681E020
Save Compare
Question about this item
Datasheet (PDF) User manual 4 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Module SMS-050-P10-1000 by Bosch Rexroth, material number R02681E020. Size SMS-050. Permissible values are up to 0.18 m/s travel speed and 3 m/s² acceleration. The weight is 5.39 kg.

Technical data

Lead10 mm
Permissible overhang C at maximum payload - wall mounting148 mm
Maximum permissible linear speed vmax0.18 m/s
Permissible overhang B at maximum payload - wall mounting26 mm
Permissible overhang C at maximum payload vertical171 mm
Permissible overhang A at maximum payload vertical171 mm
Permissible overhang A at maximum payload - wall mounting32 mm
Nominal sizeSMS-050
Maximum stroke1000 mm
Maximum payload - wall mounting24 kg
Repeatability<prefix>±</prefix>0.005<suffix></suffix> mm
Permissible overhang B at maximum payload horizontal26 mm
Permissible overhang C at maximum payload horizontal32 mm
Module height60 mm
Maximum drive torque1.1 Nm
Permissible overhang A at maximum payload horizontal148 mm
Maximum payload horizontal24 kg
Module width54 mm
Maximum payload vertical5 kg
Overall length Ltot1163 mm
Maximum acceleration rate amax3 m/s²
Weight5.39 kg
ManufacturerBosch Rexroth
Manufacturer Nr.R02681E020
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
