Module SMS-120-P32-600 by Bosch Rexroth, material number R02681L062. Size SMS-120.
Module SMS-120-P32-600 - Bosch Rexroth R02681L062
BOSCH REXROTH
Original product
Net price (excl. VAT)
€3,613.26
Item
BRR-R02681L062
Manufacturer no.
R02681L062
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R02681L062
Country of originGermany
ConditionNew
Article
BRR-R02681L062
Frequently Bought Together
-
This Item:
€3,613.26
-
Clamping piece PSK 60 - Bosch Rexroth R141901043
€22.37
-
Connecting plate CKR 12-90 K BG - Bosch Rexroth R037530016
€734.52
Total price
Module SMS-120-P32-600 by Bosch Rexroth, material number R02681L062. Size SMS-120. Permissible values are up to 1.92 m/s travel speed and 9.6 m/s² acceleration. The weight is 8.32 kg.
Technical data
| Lead | 32 mm |
|---|---|
| Permissible overhang C at maximum payload - wall mounting | 408 mm |
| Maximum permissible linear speed vmax | 1.92 m/s |
| Permissible overhang B at maximum payload - wall mounting | 251 mm |
| Permissible overhang C at maximum payload vertical | 832 mm |
| Permissible overhang A at maximum payload vertical | 832 mm |
| Permissible overhang A at maximum payload - wall mounting | 243 mm |
| Nominal size | SMS-120 |
| Maximum stroke | 600 mm |
| Maximum payload - wall mounting | 30 kg |
| Repeatability | <prefix>±</prefix>0.005<suffix></suffix> mm |
| Permissible overhang B at maximum payload horizontal | 211 mm |
| Permissible overhang C at maximum payload horizontal | 189 mm |
| Module height | 76 mm |
| Maximum drive torque | 3.1 Nm |
| Permissible overhang A at maximum payload horizontal | 341 mm |
| Maximum payload horizontal | 30 kg |
| Module width | 120 mm |
| Maximum payload vertical | 8 kg |
| Overall length Ltot | 839 mm |
| Maximum acceleration rate amax | 9.6 m/s² |
| Weight | 8.32 kg |
| Manufacturer Nr. | R02681L062 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
