Zem E S 32X20RX3,969-2 - Bosch Rexroth R151237012

Name: Zem E S 32X20RX3,969-2 - Bosch Rexroth R151237012
Brand: Bosch Rexroth
SKU: BRR-R151237012
Price: 284.71 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Zem E S 32X20RX3,969-2 by Bosch Rexroth, material number R151237012. Size 32 x 20R x 3,969 - 2.

Net

€284.71

excl. VAT

Item BRR-R151237012

Manufacturer no. R151237012

Question about this item

Datasheet (PDF) User manual 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Zem E S 32X20RX3,969-2 by Bosch Rexroth, material number R151237012. Size 32 x 20R x 3,969 - 2. The static load capacity is 21800 N. Permissible values are up to 94 m/min travel speed. The weight is 0.77 kg.

Technical data

Lead	20
Maximum permissible linear speed vmax (m/min)	94 m/min
Direction of lead	Right
Nominal size	32 x 20R x 3,969 - 2
Screw drive seal	With seal
Static load capacity C0	21800 N
Series	Standard series
Bearing temperature min	<prefix>-</prefix>15<suffix></suffix> °C
Maximum operating temperature	<prefix>+</prefix>80<suffix></suffix> °C
Nut or screw	Screw drive nut
Bearing temperature max	<prefix>+</prefix>80<suffix></suffix> °C
Category	B
Minimum operating temperature	<prefix>-</prefix>10<suffix></suffix> °C
Dynamic load capacity C	16200 N
Dimension d1	31 mm
Screw drive version (drive type)	Ball screw assembly
Nut type	ZEM-E-S cylindrical single nut
Weight	0.77 kg
Storage temperature (min. … max.)	-15 °C ... +80 °C
Operating temperature (min. … max.)	-10 °C ... +80 °C
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R151237012
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
