Fem E B 12X5RX2-3 - Bosch Rexroth R153246006

Name: Fem E B 12X5RX2-3 - Bosch Rexroth R153246006
Brand: Bosch Rexroth
SKU: BRR-R153246006
Price: 201.45 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Fem E B 12X5RX2-3 by Bosch Rexroth, material number R153246006. Size 12 x 5R x 2 - 3.

Net

€201.45

excl. VAT

Item BRR-R153246006

Manufacturer no. R153246006

Question about this item

Datasheet (PDF) User manual 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Fem E B 12X5RX2-3 by Bosch Rexroth, material number R153246006. Size 12 x 5R x 2 - 3. The static load capacity is 5800 N. Permissible values are up to 30 m/min travel speed. The weight is 0.13 kg.

Technical data

Lead	5
Maximum permissible linear speed vmax (m/min)	30 m/min
Direction of lead	Right
Nominal size	12 x 5R x 2 - 3
Screw drive seal	With seal
Static load capacity C0	5800 N
Series	Miniature series
Bearing temperature min	<prefix>-</prefix>15<suffix></suffix> °C
Maximum operating temperature	<prefix>+</prefix>80<suffix></suffix> °C
Nut or screw	Screw drive nut
Bearing temperature max	<prefix>+</prefix>80<suffix></suffix> °C
Category	A
Minimum operating temperature	<prefix>-</prefix>10<suffix></suffix> °C
Dynamic load capacity C	4560 N
Dimension d1	11.4 mm
Screw drive version (drive type)	Ball screw assembly
Nut type	FEM-E-B single nut with flange
Weight	0.13 kg
Storage temperature (min. … max.)	-15 °C ... +80 °C
Operating temperature (min. … max.)	-10 °C ... +80 °C
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R153246006
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
