Lager LAF-A-A 50 BG - Bosch Rexroth R159005030
Lager LAF-A-A 50 BG by Bosch Rexroth, material number R159005030. Size 80 x 10/20/40.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Lager LAF-A-A 50 BG by Bosch Rexroth, material number R159005030. Size 80 x 10/20/40. The static load capacity is 250000 N. The weight is 4.9 kg.
Technical data
| Rigidity of the bearing (axial) RFB | 1400 |
|---|---|
| Mounting holes t | 30 ° |
| Min. number of mounting holes | 12 |
| Bearing frictional torque with seal MRb | 2.6 Nm |
| Type | Angular-contact thrust ball bearing |
| Nominal size | 80 x 10/20/40 |
| Accessories for screw drives | Bearings |
| Static load capacity C0 | 250000 N |
| Dynamic load capacity C | 113000 N |
| Rigidity against tilting Rkl | 1500 Nm/mrad |
| Outer diameter D | 140 mm |
| Limit speed (grease) nmax | 1200 min⁻¹ |
| Weight | 4.9 kg |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R159005030 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
