Clamping element KWH 6505 AS2A for ball rail systems - Bosch Rexroth R161964251

Bosch Rexroth ✓ Original product Brand new Made in Germany

Clamping element KWH 6505 AS2A from Bosch Rexroth for size 65. Hydraulic clamping unit KWH, SLS for ball rail systems. Maximum holding force 22,700 N, holding force 22,700 N. Genuine accessory, material number R161964251.

Net
€1,977.92
excl. VAT
Item BRR-R161964251
Manufacturer no. R161964251
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Clamping and braking units hold the runner block in position without loading the drive and secure axes at standstill or in the event of a power failure. Designed for size 65, key values: maximum holding force 22,700 N, holding force 22,700 N. Manufacturer designation: Hydraulic clamping unit KWH, SLS for ball rail systems.

Benefits

  • Clamping directly on the free surfaces of the guide rail, independent of the drive
  • Maximum holding force: 22,700 N
  • Holding force: 22,700 N

Applications

Initial equipment, retrofitting and maintenance of linear axes with Bosch Rexroth profiled rail systems of size 65, in handling and assembly technology, machine tools and special machinery.

Technical data

Manufacturer part numberR161964251
VersionHydraulic clamping unit KWH, SLS for ball rail systems
Type clamping and braking unitsHydraulic
Nominal size65
Accessories forRunner Block
Maximum holding force22,700 N
Dimension B1227 mm
Holding force22,700 N
Maximum permissible ambient temperature+70 °C
Maximum hydraulic operating pressure150 bar
Displacement3.8 cm³
Weight13.01 kg
Permissible ambient temperature (min. ... max.)0 °C ... +70 °C
ManufacturerBosch Rexroth
Manufacturer Nr.R161964251
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
