Clamping element KWH 4505 BS1A for roller rail systems - Bosch Rexroth R181044211

Bosch Rexroth ✓ Original product Brand new Made in Germany

Clamping element KWH 4505 BS1A from Bosch Rexroth for size 45. Hydraulic clamping unit KWH, FLS for roller rail systems. Maximum holding force 9900 N, holding force 9900 N. Genuine accessory, material number R181044211.

Net
€1,451.37
excl. VAT
Item BRR-R181044211
Manufacturer no. R181044211
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Clamping and braking units hold the runner block in position without loading the drive and secure axes at standstill or in the event of a power failure. Designed for size 45, key values: maximum holding force 9900 N, holding force 9900 N. Manufacturer designation: Hydraulic clamping unit KWH, FLS for roller rail systems.

Benefits

  • Clamping directly on the free surfaces of the guide rail, independent of the drive
  • Maximum holding force: 9900 N
  • Holding force: 9900 N

Applications

Initial equipment, retrofitting and maintenance of linear axes with Bosch Rexroth profiled rail systems of size 45, in handling and assembly technology, machine tools and special machinery.

Technical data

Manufacturer part numberR181044211
VersionHydraulic clamping unit KWH, FLS for roller rail systems
Type clamping and braking unitsHydraulic
Nominal size45
Accessories forRunner Block
Maximum holding force9900 N
Dimension B1155 mm
Holding force9900 N
Maximum permissible ambient temperature+70 °C
Maximum hydraulic operating pressure150 bar
Displacement1.8 cm³
Weight5.35 kg
Permissible ambient temperature (min. ... max.)0 °C ... +70 °C
ManufacturerBosch Rexroth
Manufacturer Nr.R181044211
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
