Zev E S 32X5RX3,5-5 - Bosch Rexroth R254230005

Name: Zev E S 32X5RX3,5-5 - Bosch Rexroth R254230005
Brand: Bosch Rexroth
SKU: BRR-R254230005
Price: 359.97 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Zev E S 32X5RX3,5-5 by Bosch Rexroth, material number R254230005. Size 32 x 5R x 3,5 - 5.

Net

€359.97

excl. VAT

Item BRR-R254230005

Manufacturer no. R254230005

Question about this item

Datasheet (PDF) User manual 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Zev E S 32X5RX3,5-5 by Bosch Rexroth, material number R254230005. Size 32 x 5R x 3,5 - 5. The static load capacity is 50600 N. Permissible values are up to 18.8 m/min travel speed. The weight is 0.58 kg.

Technical data

Lead	5
Maximum permissible linear speed vmax (m/min)	18.8 m/min
Direction of lead	Right
Nominal size	32 x 5R x 3,5 - 5
Screw drive seal	With low-friction seal
Static load capacity C0	50600 N
Series	Standard series
Bearing temperature min	<prefix>-</prefix>15<suffix></suffix> °C
Maximum operating temperature	<prefix>+</prefix>80<suffix></suffix> °C
Nut or screw	Screw drive nut
Bearing temperature max	<prefix>+</prefix>80<suffix></suffix> °C
Category	B
Minimum operating temperature	<prefix>-</prefix>10<suffix></suffix> °C
Dynamic load capacity C	31700 N
Dimension d1	31 mm
Screw drive version (drive type)	Ball screw assembly
Nut type	ZEV-E-S screw-in nuts
Weight	0.58 kg
Storage temperature (min. … max.)	-15 °C ... +80 °C
Operating temperature (min. … max.)	-10 °C ... +80 °C
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R254230005
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
