Proximity switch BES517-398-NO-C-S49 by Bosch Rexroth, material number R901420156. The weight is 0.02 kg.
Proximity switch BES517-398-NO-C-S49 - Bosch Rexroth R901420156
BOSCH REXROTH
Original product
Net price (excl. VAT)
€64.55
Item
BRR-R901420156
Manufacturer no.
R901420156
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901420156
Country of originGermany
ConditionNew
Article
BRR-R901420156
Frequently Bought Together
-
This Item:
€64.55
-
Magnetfeldsensor REED SPDT R 12212 - Bosch Rexroth R347600903
€41.20
-
Belt drive unit SMS-080 MIS/YAS/DEL - Bosch Rexroth R02680B005
€274.86
Total price
Proximity switch BES517-398-NO-C-S49 by Bosch Rexroth, material number R901420156. The weight is 0.02 kg.
Technical data
| Type of operating voltage | DC |
|---|---|
| Functional principle | inductive |
| Suitable for drag chains | No |
| Protection class | IP65 |
| Short-circuit protection | yes |
| Mean time to dangerous failure (MTTFd) | 830 Years |
| Suitable for drag chains footnote | Technical data only for the cast-on connection line at the p |
| Torsion-resistant | no |
| Switching frequency | 2.5 kHz |
| Torsion-resistant footnote | Technical data only for the cast-on connection line at the p |
| Weld spark-resistant | no |
| Maximum permissible starting speed | depending on the length of the switching cam |
| Weld spark-resistant footnote | Technical data only for the cast-on connection line at the p |
| Reverse polarity protection | yes |
| Function indicator | yes |
| Use | Reference switch |
| Load current | <prefix>≤</prefix>200<suffix></suffix> mA |
| Bending cycles footnote | Technical data only for the cast-on connection line at the p |
| Operating voltage min. | 10 V |
| Connection type | Cable 0.2 m and connector M8 x 1, 3-pin with knurled screw |
| Cable diameter D | 3.5 mm |
| Cable diameter D tolerance | <prefix>±</prefix>0.15<suffix></suffix> mm |
| Switching function version | PNP/NO |
| Number of wires | 3 |
| Cable cross-section | 0.14 mm² |
| Dynamic bending radius footnote | Technical data only for the cast-on connection line at the p |
| Permissible ambient temperature (min) | <prefix>-</prefix>40<suffix></suffix> °C |
| Static bending radius | 12 mm |
| Permissible ambient temperature (max) | <prefix>+</prefix>70<suffix></suffix> °C |
| Dynamic bending radius | 12 mm |
| Operating voltage max. | 30 V |
| Electrical accessories for linear axes | Inductive sensors |
| Bending cycles | ‒ |
| Weight | 0.02 kg |
| Permissible ambient temperature (min. ... max.) | -40 °C ... +70 °C |
| Operating voltage (min. … max.) | 10 V ... 30 V |
| Manufacturer Nr. | R901420156 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
