Positionsschalter BNS 819-X1001-99-R-10 by Bosch Rexroth, material number R913048214. The weight is 0.08 kg.
Positionsschalter BNS 819-X1001-99-R-10 - Bosch Rexroth R913048214
BOSCH REXROTH
Original product
Net price (excl. VAT)
€157.16
Item
BRR-R913048214
Manufacturer no.
R913048214
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R913048214
Country of originGermany
ConditionNew
Article
BRR-R913048214
Frequently Bought Together
-
This Item:
€157.16
-
Dose Stecker BG - Bosch Rexroth R117560102
€228.30
-
Module SMS-030-P8-100 - Bosch Rexroth R02681C002
€952.69
Total price
Positionsschalter BNS 819-X1001-99-R-10 by Bosch Rexroth, material number R913048214. The weight is 0.08 kg.
Technical data
| Functional principle | mechanical, roller |
|---|---|
| Suitable for drag chains | No |
| Protection class | IP65 |
| Short-circuit protection | yes |
| Suitable for drag chains footnote | Technical data only for the cast-on connection line at the m |
| Torsion-resistant | yes |
| Switching frequency | 3.3 kHz |
| Torsion-resistant footnote | Technical data only for the cast-on connection line at the m |
| Weld spark-resistant | yes |
| Weld spark-resistant footnote | Technical data only for the cast-on connection line at the m |
| Reverse polarity protection | yes |
| Use | Reference switch |
| Max. permissible approach speed | 1 m/s |
| Load current | <prefix>≤</prefix>0.2<suffix></suffix> A |
| Bending cycles footnote | Technical data only for the cast-on connection line at the m |
| B10d value | 5x10<sup>6</sup> (wet area); 10x10<sup>6</sup> (dependent on |
| Operating voltage min. | 10 V DC |
| Connection type | Cable 0.2 m and connector M8 x 1, 3-pin with knurled screw |
| Cable diameter D | 4.3 mm |
| Cable diameter D tolerance | <prefix>±</prefix>0.2<suffix></suffix> mm |
| Switching function version | PNP/NO |
| Permissible ambient temperature (min) | <prefix>-</prefix>5<suffix></suffix> °C |
| Static bending radius | 12 mm |
| Permissible ambient temperature (max) | <prefix>+</prefix>70<suffix></suffix> °C |
| Dynamic bending radius | 12 mm |
| Operating voltage max. | 30 V DC |
| Electrical accessories for linear axes | Mechanical switch with M8x1 connector |
| Bending radius for flexible installation footnote | Technical data only for the cast-on connection line at the m |
| Bending cycles | ‒ |
| Compatible | CKK, CKR, MKK/MKR-065/080/110/145/165, MLR-080/110, OBB, TKL |
| Weight | 0.08 kg |
| Permissible ambient temperature (min. ... max.) | -5 °C ... +70 °C |
| Operating voltage (min. … max.) | 10 V DC ... 30 V DC |
| Manufacturer Nr. | R913048214 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
