Verification Tester for Continuous Monitors, Workstation Monitor Checker - Desco CTE701

A continuous monitor is only as reliable as its last check. Instead of removing the monitor for calibration, the Desco Workstation Monitor Checker (SCS product line) applies defined loads and signals for ground connections and wrist straps right at the workstation. You see at once whether the monitor alarms within its tolerances.

Key benefits

• No downtime: verification on site, the monitor stays installed
• Realistic test signals: resistance, impedance and voltage loads with pass and fail conditions
• EMI detection testable: high-frequency signal at two levels, normal and elevated
• Matches your specification: metal ground thresholds set via DIP switches
• Traceable calibration: NIST-traceable, certificate from the manufacturer

Applications

Periodic compliance verification of workstation and ground monitors in the EPA, for example as part of the ESD control plan. During the test the monitor stays connected to a known good ground, the monitored wires are disconnected and replaced by the checker's test leads.

Standards

Meets the ANSI/ESD S20.20 requirements for compliance verification of continuous monitors.
