Glamox 1810172D. Downlight O69-R140 LED 2500 DALI 830 MB WH

Name: Glamox 1810172D. Downlight O69-R140 LED 2500 DALI 830 MB WH
Brand: Glamox
SKU: GL-1810172D
Price: 275.1 EUR
Availability: InStock

Lead time

4 weeks

€275.10

Excl. 19% VAT , excl. Shipping Cost

Article

GL-1810172D

Manufacturer Nr.

1810172D

O69-R140 LED 2500 DALI 830 MB WH

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox 1810172D. Downlight O69-R140 LED 2500 DALI 830 MB WH
€275.10
Excl. 19% VAT , excl. Shipping Cost
Glamox 1811172. Downlight O69-R180 LED 3500 HF 830 WB WH
€282.10
Excl. 19% VAT , excl. Shipping Cost
Glamox 118271152A6. Facade D81-W150 LED 2x2300 HF 840 NB AL
€610.40
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Round
LMS System
1. Number of DALI addresses
  1
2. LMS Protocol
  DALI
Technical Data
1. Minimum ambient temperature (ºC)
  -25
2. Maximum ambient temperature (°C)
  35
3. IK classification
  05
4. IP classification
  65 from underneath \ 20 from above
5. Corrosion class
  C4
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  2,413
3. Lumen per Watt (lm/W)
  121
4. Lamp colour temp (K)
  3000
5. CRI Colour rendering index
  80
6. MacAdam step
  3
7. Minimum dim level (%)
  1
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming
2. Number of Driver
  1
Lifetime
1. L80 Median useful life LED Ta25 (hr)
  100 000
2. L70 Median useful life LED MaxTa (hr)
  100 000
3. Luminous flux decline (LLMF) 50.000h Ta25
  0.90
Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Main Feed DC (V) Min
  198
6. Main Feed DC (V) Max
  250
7. Total consumption (W)
  20
8. Number of luminaires on a 10A MCB type B (80% load)
  31
9. Number of luminaires on a 10A MCB type C (80% load)
  53
10. Number of luminaires on a 16A MCB type B (80% load)
  50
11. Number of luminaires on a 16A MCB type C (80% load)
  85

Optic
1. Optic
  MB - Medium beam
2. Material of diffuser
  Tempered glass
3. Diffuser material design
  Clear
Housing
1. Main body material
  Aluminium
2. Body colour
  White
3. Main body colour name
  White
Dimensions
1. Height (mm)
  91
2. Diameter (mm)
  140
3. Net weight (kg)
  0.81
Termination
1. Termination
  5x1.5mm2 Push In
Mounting
1. Product mounting
  Ceiling Recessed
Logistic Data
1. Item gross weight (kg)
  0.88

Information

More Information
Execution	TEC
Manufacturer Nr.	1810172D
Manufacturer	Glamox
Country of Manufacture	Germany
EAN	7020940387170
Lead time	4 weeks
Weight	0.880000
Colour	3000K
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
