Glamox 514034591. Flood light NEXT 1 LED 7000 DALI 740 MB

Name: Glamox 514034591. Flood light NEXT 1 LED 7000 DALI 740 MB
Brand: Glamox
SKU: GL-514034591
Price: 346.5 EUR
Availability: InStock

Lead time

1 week

€346.50

Excl. 19% VAT , excl. Shipping Cost

Article

GL-514034591

Manufacturer Nr.

514034591

NEXT 1 LED 7000 DALI 740 MB

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox 514034591. Flood light NEXT 1 LED 7000 DALI 740 MB
€346.50
Excl. 19% VAT , excl. Shipping Cost
Glamox O70111210. O70-S290 LED 900 HF 830 AL SMR-SEN
€313.60
Excl. 19% VAT , excl. Shipping Cost
Glamox 514034745. Flächige Strahler NEXT 8 LED 45000 DALI 830 ASY
€2,099.30
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Square
LMS System
1. Number of DALI addresses
  1
2. LMS Protocol
  DALI
Technical Data
1. Minimum ambient temperature (ºC)
  -30
2. Maximum ambient temperature (°C)
  35
3. IK classification
  09
4. IP classification
  66
5. Corrosion class
  C5
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  6,800
3. Lumen per Watt (lm/W)
  136
4. Lamp colour temp (K)
  4000
5. CRI Colour rendering index
  70
6. MacAdam step
  3
7. Energy class light source
  C
8. Minimum dim level (%)
  10
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming
2. Number of Driver
  1
Lifetime
1. L90 Median useful life LED Ta25 (hr)
  100 000
2. L80 Median useful life LED MaxTa (hr)
  100 000
Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Main Feed DC (V) Min
  180
6. Main Feed DC (V) Max
  270
7. Total consumption (W)
  50
8. Protection against surges (kV)
  4
9. Number of luminaires on a 10A MCB type B (80% load)
  9
10. Number of luminaires on a 10A MCB type C (80% load)
  15
11. Number of luminaires on a 16A MCB type B (80% load)
  15
12. Number of luminaires on a 16A MCB type C (80% load)
  25

Optic
1. Optic
  MB - Medium beam
2. Material of diffuser
  Tempered glass
3. Diffuser material design
  Clear
Housing
1. Main body material
  Aluminium
2. Body colour
  Grey
3. Main body colour name
  Silver grey
Dimensions
1. Length (mm)
  233
2. Width (mm)
  277
3. Height (mm)
  64
4. Net weight (kg)
  2.27
Cable
1. Cable Cross section (mm²)
  1.50
2. Cable End / Plug Name
  Open End
3. Cable length (m)
  1
4. Cable material
  RUBBER
5. No of leads
  5
Mounting
1. Product mounting
  Surface
Logistic Data
1. Item gross weight (kg)
  2.47

Information

More Information
Manufacturer Nr.	514034591
Manufacturer	Glamox
EAN	8019455345910
Lead time	1 week
Weight	2.470000
Colour	4000K
Lenght	233
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
