Glamox Next outdoor luminaire, 42700 lm, 3000 K, DALI dimmable
LED outdoor luminaire from the Glamox NEXT series with 42700 lm, 3000 K, Ra 80, IP66, DALI dimmable. Luminous efficacy of 128 lm/W at 334 W system power. Manufacturer part number 514034745.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Paths, car parks, façades and outdoor areas need light that withstands the weather and falls exactly where it is needed. The Glamox NEXT delivers 42700 lm at 334 W, an efficacy of 128 lm/W. The colour temperature is 3000 K with colour rendering of Ra 80. Operation: DALI dimmable. All values in the table refer to Glamox part number 514034745; when planning, please match colour temperature, control and mounting to the existing installation.
Benefits
- Luminous efficacy of 128 lm/W at 334 W system power
- Useful life of 100,000 h (L90B50, Ta 25 °C) to IEC 62717
- DALI dimmable and ready for lighting management systems
- IP66 protection: dust-tight and protected against powerful water jets
- Operates at ambient temperatures from -30 °C to +35 °C
Applications
- paths and squares
- car parks and driveways
- façades and outdoor areas
Technical data
| Manufacturer part number | 514034745 |
|---|---|
| Glamox designation | NEXT 8 LED 45000 DALI 830 ASY |
| Series | NEXT |
| Luminous flux | 42700 lm |
| System power | 334 W |
| Luminous efficacy | 128 lm/W |
| Colour temperature | 3000 K |
| Colour rendering | Ra > 80 |
| Colour tolerance (MacAdam) | 3 SDCM |
| Useful life (Ta 25 °C) | 100,000 h (L90B50) |
| Control | DALI dimmable |
| Protection rating | IP66 |
| Impact resistance | IK09 |
| Ambient temperature | -30 °C to +35 °C |
| Mounting | pole, wall surface |
| Housing | aluminium |
| Optic | ASY |
| Dimensions (L x W x H) | 633 x 481 x 92 mm |
| Weight | 14.06 kg |
| EAN | 8019455347457 |
| Manufacturer | Glamox |
| Manufacturer Nr. | 514034745 |
| GPSR manufacturer information | Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com |
| Condition of article | New |
| Article authenticity | Original product |
| Lenght | 633 |
| Control and dimming | DALI dimmable |
| Luminous flux (lumen) | 45000 lm |
| Power (W) | 334 W |
| Colour rendering (Ra) | Ra 80 |
| Protection class (IP) | IP66 |
