Glamox C75234154. Interior General Lighting C75-P1300 G2 40/60 WH 7500 WZ 840 PRE C2 MPW-SEN MP

Glamox
Lead time
4 weeks
€806.40
Excl. 19% VAT , excl. Shipping Cost
Article
GL-C75234154

Manufacturer Nr.
C75234154
C75-P1300 G2 40/60 WH 7500 WZ 840 PRE C2 MPW-SEN MP
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price

  • General

    1. Product shape
      Rectangular

  • LMS System

    1. User Control
      App
    2. Type of user interface
      Screen
    3. User Control Short Text
      App based control
    4. LMS Wireless solution
      ZigBee
    5. LMS Protocol
      Wireless

  • Technical Data

    1. Maximum ambient temperature (°C)
      25

  • Light Technical Data

    1. Light source
      LED
    2. Lumen out (lm)
      7,486
    3. Lumen per Watt (lm/W)
      141
    4. Lamp colour temp (K)
      4000
    5. CRI Colour rendering index
      80
    6. Light distribution up %
      40
    7. Light distribution down %
      60
    8. MacAdam step
      3
    9. Energy class light source
      C

  • Driver / Ballast

    1. Type of LED Driver
      WZ: Wireless Zigbee
    2. Number of Driver
      1

  • Lifetime

    1. L80 Median useful life LED Ta25 (hr)
      100 000
    2. L90 Median useful life LED Ta25 (hr)
      50 000
    3. Median useful life driver Ta25 (hr)
      100,000
    4. Luminous flux decline (LLMF) 50.000h Ta25
      0.90

  • Electrical Data

    1. Voltage from (V)
      220
    2. Maximum voltage (V)
      240
    3. Minimum frequency (Hz)
      50
    4. Maximum frequency (Hz)
      60
    5. Total consumption (W)
      56
    6. Number of luminaires on a 10A MCB type B (80% load)
      13
    7. Number of luminaires on a 10A MCB type C (80% load)
      21
    8. Number of luminaires on a 16A MCB type B (80% load)
      21
    9. Number of luminaires on a 16A MCB type C (80% load)
      35

  • Sensor

    1. Sensor type
      PIR+Daylight harvesting (CLS)
    2. Daylight functionality
      CLS
    3. Light sensor max lux
      999
    4. Light sensor min lux
      0
    5. Detection angle crosswise (°)
      62
    6. Detection angle lengthwise (°)
      84
    7. Sensor cover cross presence
      45
    8. Presence functionality
      PROG
    9. Sensor cover length presence
      62
    10. Max mounting height / detection range (metre)
      3
    11. Sensor max hold time
      Programmable
    12. Sensor min hold time
      5 sec

  • Optic

    1. Optic
      MP - Micro prismatic diffuser
    2. Material of diffuser
      Acrylic
    3. Diffuser material design
      Prismatic

  • Housing

    1. Main body material
      Aluminium
    2. Body colour
      White
    3. Main body colour name
      White

  • Dimensions

    1. Length (mm)
      1,306
    2. Width (mm)
      358
    3. Height (mm)
      40
    4. Net weight (kg)
      5.61

  • Cable

    1. Cable Cross section (mm²)
      0.75
    2. Cable End / Plug Name
      Open End
    3. Cable length (m)
      2
    4. Cable material
      Halogen/PVC free textile
    5. No of leads
      3
    6. Cable colour
      White

  • Mounting

    1. Mounting accessories
      PRE-P
    2. Product mounting
      Pendant

  • Logistic Data

    1. Item gross weight (kg)
      6.10
More Information
Manufacturer Nr. C75234154
Manufacturer Glamox
EAN 7332402341546
Lead time 4 weeks
Weight 6.100000
Colour 4000K
Lenght 1306
GPSR manufacturer information Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity Original product
Condition of article New
Download
File Icon Glamox. Catalog luxlumen (de) (13.99 MB)
