Glamox C77099257. Interior General Lighting C77-S200x1200 WH 5000 DALI 830 SM

Name: Glamox C77099257. Interior General Lighting C77-S200x1200 WH 5000 DALI 830 SM
Brand: Glamox
SKU: GL-C77099257
Price: 266.7 EUR
Availability: InStock

Lead time

1 week

€266.70

Excl. 19% VAT , excl. Shipping Cost

Article

GL-C77099257

Manufacturer Nr.

C77099257

C77-S200x1200 WH 5000 DALI 830 SM

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox C77099257. Interior General Lighting C77-S200x1200 WH 5000 DALI 830 SM
€266.70
Excl. 19% VAT , excl. Shipping Cost
Glamox A35540607. Interior General Lighting A35-S555 GR 4000 HF SMR-SEN 830
€546.00
Excl. 19% VAT , excl. Shipping Cost
Glamox C77099808. Interior General Lighting C77-S150x1200 WH 2000 HF 840 SPR-SEN SM
€249.20
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Rectangular
Certificates
1. Certification
  5 year warranty,ENEC
LMS System
1. Number of DALI addresses
  1
Technical Data
1. Minimum ambient temperature (ºC)
  -25
2. Maximum ambient temperature (°C)
  35
3. IK classification
  08
4. IP classification
  20
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  4,871
3. Lumen per Watt (lm/W)
  141
4. Lamp colour temp (K)
  3000
5. CRI Colour rendering index
  80
6. MacAdam step
  3
7. Energy class light source
  D
8. Minimum dim level (%)
  1
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming
2. Number of Driver
  1
Lifetime
1. L80 Median useful life LED Ta25 (hr)
  100 000
2. L80 Median useful life LED MaxTa (hr)
  100 000
3. Median useful life driver Ta25 (hr)
  100,000
4. Median useful life driver Ta45 (hr)
  50,000

Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Total consumption (W)
  34.57
6. Number of luminaires on a 10A MCB type B (80% load)
  12
7. Number of luminaires on a 10A MCB type C (80% load)
  21
8. Number of luminaires on a 16A MCB type B (80% load)
  21
9. Number of luminaires on a 16A MCB type C (80% load)
  35
Optic
1. Optic
  SM - Silver matt reflector
Housing
1. Main body material
  Steel
2. Body colour
  White
3. Main body colour name
  Traffic white
4. Main body colour RAL code
  RAL 9016
Dimensions
1. Length (mm)
  1,179
2. Width (mm)
  191
3. Height (mm)
  54
4. Net weight (kg)
  4.75
Termination
1. Termination
  5x2x2.5mm2 Push In
Mounting
1. Product mounting
  Surface,Ceiling Surface,Ceiling
Logistic Data
1. Item gross weight (kg)
  5.16

Information

More Information
Manufacturer Nr.	C77099257
Manufacturer	Glamox
EAN	7054130992578
Lead time	1 week
Weight	5.160000
Colour	3000K
Lenght	1179
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
