Glamox C77100069. Downlight C77-R230x230 WH 1600 DALI 830 BM

Name: Glamox C77100069. Downlight C77-R230x230 WH 1600 DALI 830 BM
Brand: Glamox
SKU: GL-C77100069
Price: 163.8 EUR
Availability: InStock

Lead time

6 weeks

€163.80

Excl. 19% VAT , excl. Shipping Cost

Article

GL-C77100069

Manufacturer Nr.

C77100069

C77-R230x230 WH 1600 DALI 830 BM

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox C77100069. Downlight C77-R230x230 WH 1600 DALI 830 BM
€163.80
Excl. 19% VAT , excl. Shipping Cost
Glamox 121021238. Downlight O69-R125 LED 800 HF 830 WB WH
€174.30
Excl. 19% VAT , excl. Shipping Cost
Glamox D35529858. Downlight D35-R180 LED 1000 DALI 840 MP
€133.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Square
Certificates
1. Certification
  5 year warranty,ENEC
LMS System
1. Number of DALI addresses
  1
Technical Data
1. Minimum ambient temperature (ºC)
  -25
2. Maximum ambient temperature (°C)
  25
3. IK classification
  08
4. IP classification
  40 from underneath \ 20 from above
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  1,409
3. Lumen per Watt (lm/W)
  71
4. Lamp colour temp (K)
  3000
5. CRI Colour rendering index
  80
6. MacAdam step
  3
7. Energy class light source
  E
8. Minimum dim level (%)
  1
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming
2. Number of Driver
  1
Lifetime
1. L80 Median useful life LED Ta25 (hr)
  100 000
2. L80 Median useful life LED MaxTa (hr)
  100 000
3. Median useful life driver Ta25 (hr)
  100,000
4. Median useful life driver Ta45 (hr)
  50,000

Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Total consumption (W)
  19.92
6. Number of luminaires on a 10A MCB type B (80% load)
  18
7. Number of luminaires on a 10A MCB type C (80% load)
  31
8. Number of luminaires on a 16A MCB type B (80% load)
  30
9. Number of luminaires on a 16A MCB type C (80% load)
  51
Optic
1. Optic
  BM - Black matt reflector
Housing
1. Main body material
  Steel
2. Body colour
  White
3. Main body colour name
  Traffic white
4. Main body colour RAL code
  RAL 9016
Dimensions
1. Length (mm)
  228
2. Width (mm)
  228
3. Height (mm)
  32
4. Cut out (mm)
  196
5. Net weight (kg)
  1.01
Termination
1. Termination
  5x2x2.5mm2 Push In
Mounting
1. Product mounting
  Ceiling Recessed
Logistic Data
1. Item gross weight (kg)
  1.10

Information

More Information
Manufacturer Nr.	C77100069
Manufacturer	Glamox
EAN	7054131000692
Lead time	6 weeks
Weight	1.100000
Colour	3000K
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
