Glamox C64092915. Medical C64-R600X600 LED 4000DALI 827-865 CCT/BBL MP/GL

Name: Glamox C64092915. Medical C64-R600X600 LED 4000DALI 827-865 CCT/BBL MP/GL
Brand: Glamox
SKU: GL-C64092915
Price: 1075.9 EUR
Availability: InStock

Lead time

4 weeks

€1,075.90

Excl. 19% VAT , excl. Shipping Cost

Article

GL-C64092915

Manufacturer Nr.

C64092915

C64-R600X600 LED 4000DALI 827-865 CCT/BBL MP/GL

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox C64092915. Medical C64-R600X600 LED 4000DALI 827-865 CCT/BBL MP/GL
€1,075.90
Excl. 19% VAT , excl. Shipping Cost
Glamox C64092923. Medical C64-R600X600 LED 6000DALI 940 MP/GL
€701.40
Excl. 19% VAT , excl. Shipping Cost
Glamox C64092912. C64-R312X1250 LED 6000HF 840 MP/PC
€688.10
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Square
Electrical Data
1. Leakage current (mA)
  0.50
2. Voltage from (V)
  220
3. Maximum voltage (V)
  240
4. Minimum frequency (Hz)
  50
5. Maximum frequency (Hz)
  60
6. Total consumption (W)
  41
7. Number of luminaires on a 10A MCB type B (80% load)
  3
8. Number of luminaires on a 10A MCB type C (80% load)
  4
9. Number of luminaires on a 16A MCB type B (80% load)
  4
10. Number of luminaires on a 16A MCB type C (80% load)
  7
LMS System
1. Number of DALI addresses
  2
Technical Data
1. Maximum ambient temperature (°C)
  40
2. IK classification
  09
3. IP classification
  65
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  4,198
3. Lumen per Watt (lm/W)
  102
4. Lamp colour temp (K)
  2700
5. Lamp colour temp (K)
  6500
6. CRI Colour rendering index
  80
7. Lamp type
  BBL - Blue Blocking Light
8. MacAdam step
  3
9. Energy class light source
  D
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming
2. Number of Driver
  2
3. No Of Ballast
  2
Lifetime
1. L80 Median useful life LED Ta25 (hr)
  100 000
2. Luminous flux decline (LLMF) 50.000h Ta25
  0.95

Optic
1. Optic
  MP/GL - Micro prismatic diffuser with glass cover
2. Material of diffuser
  Acrylic/glass
3. Diffuser material design
  Prismatic
Housing
1. Main body material
  Steel
2. Body colour
  White
3. Main body colour name
  White
Dimensions
1. Length (mm)
  597
2. Width (mm)
  597
3. Height (mm)
  93
4. Net weight (kg)
  11.48
Termination
1. Termination
  5x2x2.5mm2 Push In
Mounting
1. Product mounting
  Ceiling Recessed
Logistic Data
1. Item gross weight (kg)
  12.48
HCL
1. MDIR min
  0.20
2. MDIR max
  0.88
3. MDIR 3500K
  0.54

Information

More Information
Execution	TEC
Manufacturer Nr.	C64092915
Manufacturer	Glamox
Country of Manufacture	Germany
EAN	7054130929154
Lead time	4 weeks
Weight	12.480000
Colour	2700K
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
