Glamox O10114102. Architectural Lighting O10-S290 LED 1000 AC SMA-SEN 840 AL

Name: Glamox O10114102. Architectural Lighting O10-S290 LED 1000 AC SMA-SEN 840 AL
Brand: Glamox
SKU: GL-O10114102
Price: 301.7 EUR
Availability: InStock

Lead time

4 weeks

€301.70

Excl. 19% VAT , excl. Shipping Cost

Article

GL-O10114102

Manufacturer Nr.

O10114102

O10-S290 LED 1000 AC SMA-SEN 840 AL

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox O10114102. Architectural Lighting O10-S290 LED 1000 AC SMA-SEN 840 AL
€301.70
Excl. 19% VAT , excl. Shipping Cost
Glamox O34704316. Bollard O34 LED 700 HF 840 1000MM 180° ANTHRACITE
€660.80
Excl. 19% VAT , excl. Shipping Cost
Glamox 514045326. O52 LED 15000 740 HF d.76 WBA
€823.90
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Round
Electrical Data
1. Leakage current (mA)
  0.40
2. Voltage from (V)
  220
3. Maximum voltage (V)
  240
4. Minimum frequency (Hz)
  50
5. Maximum frequency (Hz)
  60
6. Main Feed DC (V) Min
  180
7. Main Feed DC (V) Max
  270
8. Total consumption (W)
  13
9. Number of luminaires on a 10A MCB type B (80% load)
  81
10. Number of luminaires on a 10A MCB type C (80% load)
  110
11. Number of luminaires on a 16A MCB type B (80% load)
  130
12. Number of luminaires on a 16A MCB type C (80% load)
  176
Technical Data
1. Minimum ambient temperature (ºC)
  -20
2. Maximum ambient temperature (°C)
  40
3. IK classification
  10
4. IP classification
  66
5. Corrosion class
  C4
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  955
3. Lumen per Watt (lm/W)
  80
4. Lamp colour temp (K)
  4000
5. CRI Colour rendering index
  80
6. MacAdam step
  3
7. Energy class light source
  E
Driver / Ballast
1. Type of LED Driver
  AC: Alternating Current
2. Number of Driver
  1
Lifetime
1. L70 Median useful life LED Ta25 (hr)
  100 000
2. L70 Median useful life LED MaxTa (hr)
  50 000
3. Luminous flux decline (LLMF) 50.000h Ta25
  0.85
Sensor
1. Sensor type
  MICROWAVE+LIGHT
2. Daylight functionality
  ON/OFF
3. Light sensor max lux
  5
4. Light sensor min lux
  5
5. Presence functionality
  Auto ON_OFF
6. Max mounting height / detection range (metre)
  4
7. Sensor max hold time
  5min
8. Sensor min hold time
  5min

Optic
1. Material of diffuser
  Polycarbonate
2. Diffuser material design
  Opal
Housing
1. Main body material
  Aluminium
2. Body colour
  Grey
3. Main body colour name
  Aluminium grey
Dimensions
1. Height (mm)
  131
2. Diameter (mm)
  290
3. Net weight (kg)
  2.56
Termination
1. Termination
  5x2x2.5mm2 Push In
Mounting
1. Product mounting
  Ceiling Surface,Wall Surface
Logistic Data
1. Item gross weight (kg)
  2.78

Information

More Information
Execution	TEC
Manufacturer Nr.	O10114102
Manufacturer	Glamox
Country of Manufacture	Germany
EAN	4741145295918
Lead time	4 weeks
Weight	2.780000
Colour	4000K
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
