Glamox O68581712. Downlight O68-S210 LED 3000 HF 840 MB BL

Name: Glamox O68581712. Downlight O68-S210 LED 3000 HF 840 MB BL
Brand: Glamox
SKU: GL-O68581712
Price: 475.3 EUR
Availability: InStock

Lead time

4 weeks

€475.30

Excl. 19% VAT , excl. Shipping Cost

Article

GL-O68581712

Manufacturer Nr.

O68581712

O68-S210 LED 3000 HF 840 MB BL

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox O68581712. Downlight O68-S210 LED 3000 HF 840 MB BL
€475.30
Excl. 19% VAT , excl. Shipping Cost
Glamox D35531059. D35-S280 LED 1400 DALI 830 OP
€175.00
Excl. 19% VAT , excl. Shipping Cost
Glamox D40533697. D40-R70F WH LED 500 AC 830 25°
€72.80
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Round
Technical Data
1. Minimum ambient temperature (ºC)
  -25
2. Maximum ambient temperature (°C)
  35
3. IK classification
  08
4. IP classification
  66
5. Corrosion class
  C4
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  3,150
3. Lumen per Watt (lm/W)
  90
4. Lamp colour temp (K)
  4000
5. CRI Colour rendering index
  80
6. MacAdam step
  3
7. Energy class light source
  D
Driver / Ballast
1. Type of LED Driver
  HF: High Frequency
2. Number of Driver
  1
Lifetime
1. L80 Median useful life LED Ta25 (hr)
  50 000
2. L70 Median useful life LED MaxTa (hr)
  50 000
3. Luminous flux decline (LLMF) 50.000h Ta25
  0.80
Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Main Feed DC (V) Min
  180
6. Main Feed DC (V) Max
  270
7. Total consumption (W)
  35
8. Number of luminaires on a 10A MCB type B (80% load)
  9
9. Number of luminaires on a 10A MCB type C (80% load)
  16
10. Number of luminaires on a 16A MCB type B (80% load)
  15
11. Number of luminaires on a 16A MCB type C (80% load)
  25

Optic
1. Optic
  MB - Medium beam
2. Material of diffuser
  Tempered glass
3. Diffuser material design
  Clear
Housing
1. Main body material
  Aluminium
2. Body colour
  Black
3. Main body colour name
  Black
Dimensions
1. Height (mm)
  220
2. Diameter (mm)
  211
3. Net weight (kg)
  3.59
Termination
1. Termination
  3x2.5mm2 Screw Terminal
Mounting
1. Product mounting
  Ceiling Surface
Logistic Data
1. Item gross weight (kg)
  3.90

Information

More Information
Execution	TEC
Manufacturer Nr.	O68581712
Manufacturer	Glamox
Country of Manufacture	Germany
EAN	8054378309250
Lead time	4 weeks
Weight	3.900000
Colour	4000K
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
