FT-45 smart home kit, crimp tool and 10 Cat5e RJ-45 plugs - IDEAL 30-5016EU

For a few network drops in a smart home or a small retrofit, a full tool range is not worth it. This kit contains the FT-45 crimp tool and 10 Cat5e modular plugs, so the first cables can be terminated right away. The FT-45 trims the fed-through wires flush during crimping, with no separate trimming step.

Benefits

• Ready to use: crimp tool and 10 matching Cat5e plugs in one pack
• Crimps and trims the conductors flush in one stroke
• Wiring order can be checked in the open plug before crimping
• Clear storage box (as shown in product image), total weight 336 g

Applications

• Network cabling in smart homes and residential buildings
• Retrofitting single network outlets in offices and workshops
• Termination of Cat5e patch cords

Usage notes

• Unshielded plugs: remove 25-38 mm of jacket and remove the centre spline on Cat6 cable.
• Untwist pairs to the jacket base, align in order, trim the ends flat and verify the wiring order before crimping.
