corner table top Quadro trapezoidal incl. cable tray, 40 mm - Karl 10.916.88

This table top forms the work surface of a KARL QUADRO table: as a trapezoidal corner (front edge 900 mm, depth 880 mm), 880 mm deep and 40 mm thick with a rounded postformed front edge. It is fixed to the QUADRO columns with the supplied mounting kit and can be mounted at any height. As a corner top it joins two QUADRO tables at an angle to form a corner combination.

Benefits

• High-pressure laminate surface (EN 438), a very hard and abrasion-resistant HPL: lightly textured, glare-free and highly scratch-resistant.
• Heat-resistant up to 180 °C for short periods and resistant to organic solvents, weak acids and alkalis, petrol and oil.
• 40 mm top with rounded postformed front edge, protected by a hard-wearing edge banding.
• Cut-outs for the QUADRO columns and mounting kit, infinitely height-adjustable mounting. Minimum height with mobile drawer cabinets: 780 mm.
• Sheet-steel cable tray under the table top with access to the QUADRO columns, cable feed-throughs (80 mm diameter) at the rear of the top as access to the tray, cable feed-through sets included.

Matching accessories and variants

• ESD version: KARL 10.916.89
• Basic equipment version: KARL 10.906.88
• Sheet-steel storage shelf trapezoidal corner: KARL 14.095.70
• Privacy screen trapezoidal corner: KARL 14.535.70

Applications

• Assembly, production and test areas
• Extending or converting existing QUADRO workstations
• Corner combinations and table rows with QUADRO tables
• Workstations with many devices and cables, e.g. measuring and test equipment
