Support rail for picking bins Quadro incl. Vario multifunction arm - Karl 14.601.70

Name: Support rail for picking bins Quadro incl. Vario multifunction arm - Karl 14.601.70
Brand: Karl
SKU: KL-14.601.70
Price: 285.18 EUR
Availability: InStock

Karl ✓ Original product Brand new Made in Germany

Curved support rail with VARIO multifunction arm for 7 Schäfer system picking bins, size 5: all parts sit in a semicircle around the operator. Extendable upwards or downwards, load rating max. 30 kg.

Net

€285.18

excl. VAT

Item KL-14.601.70

Manufacturer no. 14.601.70

Question about this item

Datasheet (PDF) 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Picking bins arranged in an arc shorten reach distances in manual assembly. This support rail holds 7 Schäfer system picking bins, size 5, sits on the VARIO multifunction arm and is positioned at any height on the QUADRO column.

Benefits

Curved layout for short reach distances.
Holds 7 Schäfer system picking bins, size 5.
Extendable upwards or downwards with further rails (KARL 14.602.70).
Load rating max. 30 kg.
VARIO multifunction arm with 3 self-locking joints and length-adjustable swivel arms, infinitely height-adjustable on the QUADRO column, mounted standing or hanging.

Matching accessories and variants

Extension support rail: KARL 14.602.70
Picking bin shelf incl. VARIO multifunction arm: KARL 14.606.70
Picking bin support rail for SINTRO: KARL 39.601.70

Applications

Assembly, test and repair workstations in electronics manufacturing
EPA workstations with the QUADRO table system in ESD version
Lean production workstations with tools and materials within easy reach

Technical data

Manufacturer part no.	14.601.70
Version	base element, curved
Picking bins	7, Schäfer system, size 5
Extension	upwards or downwards with KARL 14.602.70
Load rating	max. 30 kg
Multifunction arm	VARIO included
Mounting	infinitely height-adjustable on the QUADRO column
Made in	Germany
Weight	1 kg
Manufacturer	Karl
Manufacturer Nr.	14.601.70
Note	inkl. Multifunktionsarm VARIO
GPSR manufacturer information	Andreas KARL GmbH & Co. KG, Hauptstraße 26, DE-85777 Fahrenzhausen, www.karlnet.de
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Ausführung	Grundelement
Load capacity (kg)	30
