ESD table frame TriMax Light, electrically height-adjustable, 1800x800 mm - Karl 160.422.100.78

Set the working height to person and task at the push of a button: the KARL TriMax Light table frame moves infinitely from 760 to 1160 mm on a spindle lift system and carries 3000 N per frame. Built for 1800 x 800 mm table tops, the ESD version is conductive and has an integrated earthing system for EPA workstations.

Benefits

• 400 mm stroke (760 to 1160 mm) at a lifting speed of 20 mm/s.
• Desk panel with 3 programmable memory keys, plus lowest and highest position programmable and directly selectable.
• Synchronous control of two table frames possible, for continuous work lines at the same height.
• Lifting columns made of two clear anodised aluminium profiles, C-foot system in jet black (RAL 9005).
• Integrated earthing system, ESD version conductive.

Matching accessories and variants

• Standard version without ESD: KARL 160.422.000.78
• ESD HPL table top 1800 x 800 mm: KARL 200.421.10
• Cable tray with privacy screen for 1800 mm table width: KARL 190.115.48
• Power cable with Swiss plug (CH): KARL 95.628.98
• Monitor mount set Light: KARL 190.610.70

Applications

• EPA workstations in electronics manufacturing and repair
• Quality assurance, test areas and measurement rooms
• Development and prototyping with changing operators in shift work
