ESD table frame TriMax Comfort, electrically height-adjustable, 2000x800 mm - Karl 162.622.100.78

Set the working height to person and task at the push of a button: the KARL TriMax Comfort table frame moves infinitely from 745 to 1145 mm on a spindle lift system and carries 4000 N per frame. Built for 2000 x 800 mm table tops, the ESD version is conductive and has an integrated earthing system for EPA workstations.

Benefits

• 400 mm stroke (745 to 1145 mm) at a lifting speed of 12 mm/s.
• Desk panel with 4 programmable memory keys, plus lowest and highest position programmable and directly selectable.
• Synchronous control of several table frames possible, for continuous work lines at the same height.
• Lifting columns made of two clear anodised aluminium profiles, C-foot system in jet black (RAL 9005).
• Integrated earthing system, ESD version conductive.

Matching accessories and variants

• Standard version without ESD: KARL 162.622.000.78
• ESD HPL table top with profile cut-outs for Comfort vertical struts 2000 x 800 mm: KARL 200.621.14
• Vertical strut Comfort, left: KARL 190.120.70
• Vertical strut Comfort, right: KARL 190.121.70
• Cable tray with privacy screen for 2000 mm table width: KARL 190.115.68
• Power cable with Swiss plug (CH): KARL 95.628.98

Applications

• EPA workstations in electronics manufacturing and repair
• Quality assurance, test areas and measurement rooms
• Development and prototyping with changing operators in shift work
