ESD 19-inch wooden superstructure for QUADRO-CAR, 6 U, without main switch module and central wiring harness - Karl 19.915.34

This 19-inch superstructure turns the QUADRO-CAR into a mobile test station: it holds 6 U subracks with up to 60 kg installed weight and mounts at any height between the QUADRO columns. This version comes without main switch module and central wiring harness for your own wiring. ESD version for use in EPAs.

Benefits

• Sturdy conductive wooden housing in light grey, 350 mm deep.
• Mounting rails at standardised spacing to DIN 41 494 for test and measurement equipment.
• Perforated back panel for adequate ventilation of the instruments.
• Infinitely height-adjustable mounting, installed weight up to 60 kg.

Matching accessories and variants

• Standard version: KARL 19.915.30
• Version with main switch module and central wiring harness: KARL 19.919.34
• 3 U version: KARL 19.905.34
• Standard storage shelf QUADRO-CAR, D = 465 mm: KARL 19.405.70
• Pull-out storage shelf QUADRO-CAR with mouse tray: KARL 19.470.70
• 3 m mains cable with Schuko plug and WINSTA socket: KARL 95.625.98

Applications

• Mobile test stations in EPAs
• Commissioning and service on plant and machinery
• Test areas, laboratories and quality assurance
