Table top TriMax Comfort high-pressure laminate, 1800x800 mm, with profile cut-outs for Comfort vertical struts - Karl 200.421.04

Name: Table top TriMax Comfort high-pressure laminate, 1800x800 mm, with profile cut-outs for Comfort vertical struts - Karl 200.421.04
Brand: Karl
SKU: KL-200.421.04
Price: 465.60 EUR
Availability: InStock

Karl ✓ Original product Brand new Made in Germany

Table top 1800 x 800 mm for height-adjustable KARL TriMax workstations, 30 mm thick, with profile cut-outs on both sides for the vertical struts of the Comfort version. Light grey HPL surface, glare-free and highly scratch-resistant, heat-resistant up to 160 °C.

Net

€465.60

excl. VAT

Item KL-200.421.04

Manufacturer no. 200.421.04

Question about this item

Datasheet (PDF) 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

This table top forms the work surface of TriMax Comfort table frames in 1800 x 800 mm. It comes factory-prepared with profile cut-outs on both sides for the vertical struts of the Comfort version, so the Comfort vertical struts fit without rework.

Benefits

High-pressure laminate (HPL) surface in light grey: hard-wearing, lightly textured, glare-free and highly scratch-resistant.
White HPL backing layer on the underside keeps the 30 mm top dimensionally stable.
Tested to EN 438-2, surface resistant to dry heat up to 160 °C.
Resistant to organic solvents, weak acids and alkalis, petrol and oil.
Factory-machined: profile cut-outs on both sides for the vertical struts of the Comfort version.

Matching accessories and variants

Table frame Comfort 1800 x 800 mm: KARL 162.422.000.78
Vertical strut Comfort, left: KARL 190.120.70
Vertical strut Comfort, right: KARL 190.121.70
Cable tray 1800 mm for cable routing under the table top: KARL 190.115.48
ESD version, dissipative to IEC 61340-5-1: KARL 200.421.14

Applications

Assembly, production and test areas
Height-adjustable sit-stand workstations with computers, measuring instruments and tools
Laboratories and work preparation in technical environments

Technical data

Manufacturer part no.	200.421.04
Series	KARL TriMax, for TriMax Comfort table frames
Dimensions (W x D)	1800 x 800 mm
Thickness	30 mm
Surface	high-pressure laminate (HPL), light grey
Underside	white HPL backing layer
Edge	light grey edge banding
Machining	profile cut-outs on both sides for the vertical struts of the Comfort version
Test standard	EN 438-2
Heat resistance	dry heat up to 160 °C (surface)
ESD version	no, standard version
Made in	Germany
Weight	1 kg
Manufacturer	Karl
Manufacturer Nr.	200.421.04
Note	Profilausschnitt für Comfort-Vertikalstreben
GPSR manufacturer information	Andreas KARL GmbH & Co. KG, Hauptstraße 26, DE-85777 Fahrenzhausen, www.karlnet.de
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Height	30 mm
Width	1800 mm
Depth	800 mm
Colour	Light Grey
Ausführung	Standard
