ESD side cabinet wood version with hinged doors, 1000x450x772 mm - Karl 510.421.01

Keep files, documents and working material locked away right at the workstation: this low side cabinet from the KARL wood range holds two file heights within 772 mm and matches KARL workstation systems in look and function. The ESD version complies with IEC 61340-5-1 and is built for EPAs in electronics manufacturing.

Benefits

• 19 mm light grey particleboard carcass with melamine-resin surface: scratch-resistant, hard-wearing and easy to clean.
• High lateral stability from the compact construction: carcass fully dowelled and glued, all edges with 2 mm ABS banding, 13 mm grooved-in back panel.
• 28 mm shelf adjustable in the 32 mm hole pattern of the side panels, metal shelf supports with locking pin.
• Hinged doors on 270° hinges.
• Espagnolette lock with rotary knob, suitable for master-key systems, with folding key.
• Plinth with concealed metal levelling feet to compensate for uneven floors.

Matching accessories and variants

• Additional ESD shelf 960 x 400 mm: KARL 710.411.11
• Standard version without ESD: KARL 510.421.00
• Taller version, 1352 mm with three file heights: KARL 510.431.01

Applications

• EPAs in electronics manufacturing, repair and test areas
• Storage of files, documentation, test equipment and small parts at the workstation
• Offices and laboratories in technical environments
