table top element, rear, Quadro transfer line 2/3, right-hand outfeed, track width 300 mm, table width 2135 mm - Karl 55.763.88

With a transfer line over 2/3 of the table width, part of the table surface remains open. The rear table top element covers the table area behind the transfer line and turns it into usable work and storage space. It fits Quadro work tables with 2135 mm table width and right-hand outfeed, for a transfer line track width of 300 mm.

Benefits

• Light grey work surface in high-pressure laminate (EN 438) with hard-wearing edge banding.
• Matched to the Quadro transfer line over 2/3 of the table width with 1360 mm roller or skate-wheel strips.
• Cut to the 300 mm track width, with a dedicated rear element for each track width of 300, 400 and 600 mm.

Matching accessories and variants

• ESD version in conductive ESD laminate: KARL 55.763.89
• Side table top element for 2135 mm table width: KARL 55.798.88
• Rear table top element for the other track widths: KARL 55.773.88 / 55.783.88
• Same element for left-hand outfeed: KARL 55.764.88
• roller strips 1360 mm, track width 300 mm: KARL 55.663.72
• skate-wheel strips 1360 mm: KARL 55.563.72

Applications

• Assembly and test stations in production
• Linked workstations with manual workpiece carrier transfer
• Storage of tools, components and test equipment beside or behind the transfer line
