table top element, rear, Sintro transfer line 2/3, track width 300 mm, table width 1530 mm - Karl 56.733.88

With a transfer line over 2/3 of the table width, part of the table surface remains open. The rear table top element covers the table area behind the transfer line and turns it into usable work and storage space. It fits Sintro work tables with 1530 mm table width, for a transfer line track width of 300 mm.

Benefits

• Light grey work surface in high-pressure laminate (EN 438) with hard-wearing edge banding.
• Resistant to organic solvents, weak acids and alkalis, petrol and oil.
• Matched to the Sintro transfer line over 2/3 of the table width with 1020 mm roller or skate-wheel strips.
• Cut to the 300 mm track width, with a dedicated rear element for each track width of 300, 400 and 600 mm.
• Can be raised to workpiece carrier level with the 38 mm spacer set.

Matching accessories and variants

• ESD version in conductive ESD laminate: KARL 56.733.89
• Side table top element for 1530 mm table width: KARL 56.794.88
• Rear table top element for the other track widths: KARL 56.743.88 / 56.753.88
• roller strips 1020 mm, track width 300 mm: KARL 56.633.72
• skate-wheel strips 1020 mm: KARL 56.533.72
• Spacer set for rear table top element, 38 mm: KARL 55.907.70

Applications

• Assembly and test stations in production
• Linked workstations with manual workpiece carrier transfer
• Storage of tools, components and test equipment beside or behind the transfer line
