ESD transport trolley for workpiece carriers with flanged roller strips, track width 300 mm - Karl 58.505.70

Move workpieces on their carrier without re-handling them: the KARL transport trolley docks onto the transfer line, takes over the carrier via its flanged roller strips with 300 mm track width and rolls it on 4 swivel castors to the next workstation. The ESD version is part of the KARL ESD system compliant with IEC 61340-5-1.

Benefits

• Docking system for fixing to the roller conveyor or flanged roller strips: automatic locking when docking, released with one hand movement.
• Top-mounted flanged roller strips with clamping element to hold one workpiece carrier in place during transport.
• Side trolley made of square steel tube on 4 swivel castors.
• Intermediate shelf in light grey (RAL 7035) as additional storage.

Matching accessories and variants

• Counterpart for the docking system, mounted on the table or roller conveyor: KARL 58.598.70
• Standard version without ESD: KARL 58.505.72
• Version with roller conveyor, track width 300 mm: KARL 58.565.70
• End stop for flanged roller strips, track width 300 mm: KARL 59.105.70

Applications

• Transfer lines split into sections for structural reasons, with workpieces transported on the carrier
• Removing defective workpieces to a repair station and feeding them back in
• Taking assembled workpieces to test stations or endurance test rigs
