ESD top cabinet wood version with glazed hinged doors, 800x650x1292 mm - Karl 608.632.01

Keep files and documents visible yet protected from dust: this top cabinet with glazed hinged doors from the KARL wood range holds 3 file heights within 1292 mm. Placed on a 772 mm side cabinet, the combination reaches the 2064 mm of KARL tall cabinets. The ESD version complies with IEC 61340-5-1 and is built for EPAs in electronics manufacturing.

Benefits

• 19 mm light grey particleboard carcass with melamine-resin surface: scratch-resistant, hard-wearing and easy to clean.
• High lateral stability from the compact construction: carcass fully dowelled and glued, all edges with 2 mm ABS banding, 13 mm grooved-in back panel.
• 28 mm shelves adjustable in the 32 mm hole pattern of the side panels, metal shelf supports.
• Hinged doors with 4 mm safety glass inserts: contents visible at a glance, 270° hinges.
• Espagnolette lock with rotary knob, suitable for master-key systems, with folding key.

Matching accessories and variants

• Additional ESD shelf 760 x 600 mm: KARL 708.611.11
• Standard version without ESD: KARL 608.632.00
• Matching base, side cabinet with hinged doors, 772 mm high: KARL 508.621.01
• Same version, 450 mm deep: KARL 608.432.01

Applications

• EPAs in electronics manufacturing, repair and test areas
• Cabinet runs of KARL wooden cabinets up to 2064 mm high
• Offices and laboratories in technical environments
