Weight Basket for Block Weights OIML M1 - KERN 346-052-010

The KERN 346-052-010 combines a test weight and a carrying basket, a basket adjusted to OIML class M1 with a 50 kg own value for test loads up to 250 kg. It suits the testing of high-capacity floor, pallet and crane scales and also stores the weights between checks.

Benefits

• Testing in one lift: the basket and its block weights are placed together, saving time on every check.
• Adjusted to OIML class M1: 50 kg own value, permissible tolerance ± 2,5 g.
• High test load: maximum total weight of 250 kg with basket and weights.
• Flexible loading: possible configuration 10 × 20 kg (block weights).
• Storage included: the basket keeps the weights dust-protected between tests.

Technical data

• OIML accuracy class: M1
• Basket own value: 50 kg
• Permissible OIML tolerance: ± 2,5 g
• Possible loading (block weights): 10 × 20 kg
• Max. total weight (basket incl. weights): 250 kg

Compliance and origin

Adjusted to OIML accuracy class M1. Other accuracy classes are available on request. EAN 4045761225077, customs tariff code 84239090, country of origin Germany.
