Weight Basket for Control Weights OIML M1 - KERN 347-062-022

For checking high-capacity floor, pallet and crane scales, the KERN 347-062-022 bundles the test weights in a basket that doubles as their storage. Basket and weights go onto the scale in one step, which saves time at every calibration check.

Benefits

• Adjusted to OIML class M1: traceable checking with a permissible tolerance of ± 3 g on the basket nominal value of 60 kg
• Single-step handling: place the basket including weights together instead of stacking individual weights
• High test load: loading with 22×20 kg, max. total weight 500 kg
• Other classes available: further OIML accuracy classes on request

Technical data

• OIML accuracy class: M1
• Nominal value (basket): 60 kg
• Permissible tolerance (OIML): ± 3 g
• Possible loading: 22×20 kg
• Max. total weight (basket incl. weights): 500 kg
• Basket own weight: 60 kg

Applications

Standardised checking of high-capacity floor scales, pallet scales, weighing lift trucks and crane scales.

Compliance and origin

EAN 4045761225046, customs tariff code 84239090, origin Germany.
