Floor Scale 300 kg / 600 kg Readability 0,05 kg / 0,1 kg - KERN BID 600K-1DS

The KERN BID 600K-1DS weighs pallets, mesh boxes and bulk goods at floor level up to 300 kg / 600 kg and, as a multi-range scale, switches automatically to the next range as the load grows. In the lower range it reads down to 0,05 kg, and the 1000 x 1000 mm platform takes bulky loads safely.

Benefits

• Automatic range switching: fine resolution from 0,05 kg in the lower range, full capacity up to 600 kg.
• Non-slip steel bridge (IP67): four silicone-coated load cells in alloy steel and a chequer plate for a secure stand.
• Evaluation unit with IP65 rating: plastic housing, protected against dust and splash water for warehouse and production.
• Service-friendly: levelling and junction-box access from above, weighing plate removable for cleaning.
• Network-ready: RS-232 as standard, optional Ethernet, USB or WLAN, remote control via the KERN Communication Protocol (KCP).

Technical data

• Weighing range (Max): 300 kg / 600 kg
• Readability (d): 0,05 kg / 0,1 kg
• Repeatability: 0,1 kg / 0,2 kg
• Linearity: ± 0,3 kg / 0,6 kg
• Weighing system: Strain gauge
• Stabilization time: 2 s
• Weighing area (W x D): 1000 x 1000 mm
• Platform height: 108 mm
• Display: LCD, digit height 25 mm
• Protection: Evaluation unit IP65, bridge IP67
• Interfaces: RS-232 standard, optional Ethernet, USB, WLAN
• Operating temperature: -10 °C to 40 °C
• Net weight: 75 kg

Applications

The floor scale suits warehouse logistics, industry and production, wholesale and forwarding as well as order picking and dispatch.

Compliance and origin

Evaluation device KERN KIB-TM, compliant with CE and RoHS. Country of manufacture China. EAN 4045761275645, customs tariff number 84238220.
