Counting System - KERN CCA 30K-4M

The KERN CCA 30K-4M counts the smallest parts in large quantities and replaces a whole range of single scales. The high-resolution EWJ reference scale (6 kg, 100 mg readability) determines the piece weight, the bulk scale up to 15 kg / 30 kg does the counting, and up to 999,999 pieces are displayed.

Benefits

• Two-scale counting system: the EWJ reference scale sets the piece weight while the bulk scale counts large quantities with high precision.
• Reliable small-part counting: smallest piece weight from 100 mg under lab conditions.
• Up to 999,999 pieces: three displays show weight, reference weight and total count at the same time.
• Internal adjustment automation: time-controlled every 2 h for location-independent accuracy without manual readjustment.
• 100 item memories: reference weight, reference quantity and tare deduction recalled directly for recurring jobs.
• Verifiable on request: available for legal-for-trade use, RS-232 as standard with Y cable and printer connection.

Technical data

• Bulk scale - weighing range (Max): 15 kg / 30 kg
• Bulk scale - readability (d): 0,005 kg / 0,01 kg
• Reference scale - weighing range (Max): 6 kg
• Reference scale - readability (d): 100 mg
• Smallest piece weight (lab conditions): 100 mg
• Smallest piece weight (normal conditions): 1 g
• Max. pieces displayed: 999,999
• Weighing system: Strain gauge
• Stabilization time: 2 s
• Bulk weighing area (W x D): 400 x 300 mm
• Display: LCD, digit height 20 mm
• Protection bulk scale: IP65
• Interface: RS-232 standard
• Operating temperature: 0 °C to 40 °C
• Net weight: 14 kg

Applications

The counting system is designed for the packaging industry, general counting tasks, warehouse logistics, quality assurance as well as order picking and stocktaking.

Compliance and origin

KERN EWJ reference scale and bulk scale, verifiable on request. Country of manufacture China. EAN 4045761276413, customs tariff number 84238129.
