Counting System - KERN CCS 1T-4

The KERN CCS 1T-4 is a counting system for series production and warehouse logistics. It counts small parts in large quantities by determining the single-piece weight on a precise reference scale (6 kg / 100 mg) and capturing the amount on the bulk scale up to 1500 kg with 0,5 kg readability. One unit replaces a whole set of individual scales.

Benefits

• Two-scale counting principle: a high-resolution reference scale (6 kg / 100 mg) determines the part weight while the bulk scale (1500 kg / 0,5 kg) counts large quantities.
• Fine counting resolution: smallest part weight 100 mg under laboratory conditions, 1 g under normal conditions.
• Large batches at a glance: up to 999,999 counted parts can be displayed.
• Built for the shop floor: IP67 protection class and an aluminium single-point load cell handle rough use.
• Data connectivity: RS-232 serienmäßig lets you connect a printer or PC directly.
• Fill-to-target function: program a target count and reaching it is signalled acoustically and visually.

Technical data

• Bulk scale - weighing range (Max): 1500 kg
• Bulk scale - readability (d): 0,5 kg
• Reference scale - weighing range (Max): 6 kg
• Reference scale - readability (d): 100 mg
• Repeatability: 0,0002 kg
• Smallest part weight (laboratory conditions): 100 mg
• Smallest part weight (normal conditions): 1 g
• Weighing system: Dehnungsmessstreifen
• Weighing surface (W x D): 1200×1500 mm
• Display: LCD, digit height 20 mm
• Interface: RS-232 serienmäßig
• Protection class: IP67
• Ambient temperature: 0 °C to 40 °C
• Net weight approx.: 110 kg

Applications

Packaging industry, counting tasks, warehouse logistics, quality assurance as well as order picking and stocktaking.

Compliance and origin

Aluminium single-point load cell, IP67 protection class. Country of manufacture China. EAN 4045761235878, customs tariff number 84238220.
