Digital Microscope Set 4x - KERN OBL 137C832

The KERN OBL 137C832 is a ready-to-use digital microscope set: the trinocular OBL 137 infinity transmitted-light microscope with an adapted KERN ODC 832 C-mount camera. The camera streams the live image straight to the PC. The supplied KERN Microscope VIS Basic software with a stage micrometer enables calibration, image documentation and measurement. Objectives 4x / 10x / 40x / 100x reach 40x to 1000x with the 10x eyepiece.

Benefits

• Live imaging and documentation: ODC 832 (5,1 MP, CMOS, 1/2,5")
• Ready to connect: interfaces USB 3.0
• Plane infinity optics: Infinity E-Plan objectives 4x / 10x / 40x / 100x
• Matching adapter included: C-mount adapter included, powered over the USB cable
• Köhler illumination: pre-centred Köhler illumination with 1,25 Abbe condenser

Technical data

• Optical system: Infinity
• Objective class: Infinity E-Plan
• Objectives: 4x / 10x / 40x / 100x
• Tube: Trinokular
• Tube inclination: 30°
• Eyepiece: 10x
• Eyepiece field of view: 20 mm
• Interpupillary distance: 50 mm - 75 mm
• Nosepiece positions: 4
• Transmitted-light illumination: LED, 3W
• Light-path split: 20:80
• Camera resolution: 5,1 MP
• Camera sensor: CMOS, 1/2,5"
• Interfaces: USB 3.0
• Power supply: Netzteil (100 - 240 V)
• Net weight: 8 kg

Compliance and origin

EAN 4045761228818. Customs tariff number 90118000. Country of origin China.
