Sensor cable 2.5 m, 4-pin, M12 plug/M12 socket, A-coded, 24V DC - LED2WORK 200100-02

The 24V DC sensor cable connects LED2WORK 24V DC luminaires with an M12-A connection over a length of 2.5 m. It is 4-core, black, with an A-coded M12 socket on one end and an A-coded M12 plug on the other. RGB and RGB-W luminaires require a 5-core sensor cable for the signal function.

Key benefits

• 2.5 m length for compact connection of 24V DC luminaires
• 4-core, A-coded, M12 on both ends (plug and socket)
• Rated IP65, IP67 and IP68 when fitted
• PUR jacket, high current rating of 4000 mA per pin
• Gold-plated contacts and nickel-plated coupling nut for reliable connections

Technical data

• Model: sensor cable, M12 socket, 4-pin
• Coding: A-coded, 4 poles
• Cable length: 2.5 m
• Cable ends: M12 plug straight / M12 socket straight
• Cable material: PUR, black
• Contact material: metal, CuSn, gold-plated
• Coupling nut material: metal, CuZn, nickel-plated
• Seal material: FPM / FKM
• Rated voltage: 250 V
• Current rating per pin: 4000 mA
• Ambient temperature: -30 °C to +90 °C
• Protection rating (fitted): IP65, IP67, IP68
• Standards: IEC 61076-2-101
• Conductor cross-section: 0.34 mm²
• Weight: 100 g
• Certifications: CE, RoHS, UL
• Made in: Germany

Applications

For connecting LED2WORK 24V DC luminaires with an M12-A connection, except RGB and RGB-W luminaires, which require a 5-core sensor cable.
