Field-wireable 230V AC cable with an S-coded M12 socket and four open wire ends. 5 m of PUR cable with 1.5 mm² conductors, sealed to IP68 when fitted. For LED2WORK luminaires with an M12-S port.
Sensor cable 4-pin PUR 5 m, M12 socket S-coded to open ends, 220-240V AC - LED2WORK 200100-14
LED2WORK Original product
Net price (excl. VAT)
€43.47
Item L2W-200100-14
Manufacturer no. 200100-14
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.200100-14
Country of originGermany
Customs tariff number85444290
ConditionNew
Article
L2W-200100-14
Frequently Bought Together
- This Item: €43.47
- TUBELED_40 II RGB-W ECO Machine and Signal Light 280 mm, 100° - LED2WORK 118190-02 €153.47
- Daylight SP25171E. Power supply for E25171 €9.09
Total price
Safely supplies mains voltage to LED2WORK 230V AC luminaires with an S-coded M12 port. One end carries a ready S-coded M12 socket, the other four open wire ends for free connection, sealed to IP68 once mounted. The larger 1.5 mm² cross-section is rated for the higher voltage.
Key benefits
- S-coded M12 socket rated for 230V AC supply
- 1.5 mm² conductor cross-section, load up to 12 A per pin
- 5 m of 4-core black PUR cable with four open wire ends for free wiring
- Protection rating IP65, IP67 and IP68 when fitted
- Wide operating range from -30 °C to +90 °C
Technical data
- Model: sensor cable, open / M12 socket S-coded, 4-pin
- Design: PUR, black
- Coding: S-coded
- Cable length: 5 m
- Number of pins: 4
- Cable ends: open ends, 4 cores / M12 socket S-coded straight
- Conductor cross-section: 4x 1.5 mm²
- Rated voltage: 630V AC, 600V AC (UL)
- Current load per pin: 12 A
- Operating temperature: -30 °C to +90 °C
- Protection rating (fitted): IP65, IP67, IP68
- Cable material: PUR
- Contact material: metal, CuSn, gold-plated
- Coupling nut material: metal, CuZn, nickel-plated
- Seal material: FPM / FKM
- Standards: IEC 61076-2-111
- Weight: 600 g
- Certifications: CE, RoHS, UL
Applications
For connecting LED2WORK 230V AC luminaires with an S-coded M12 plug to the mains supply. The open wire ends allow field termination on the supply side.
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 200100-14 |
| Manufacturer | LED2WORK |
| Country of Manufacture | Germany |
| Weight | 0.600000 |
| HS-Code | 85444290 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
