F+B sensor cable TPE 5 m, M12 socket to 5 open leads, FDA - LED2WORK 201100-10

Connect LED2WORK RGB and RGB-W luminaires in food and beverage production. The grey 5-core TPE sensor cable is built entirely from FDA-approved materials over 5 m and supports the signal function of these luminaires with its additional core.

Key benefits

• 5 cores, made for RGB and RGB-W luminaires with signal function
• Built entirely from FDA-approved materials, suitable for food and beverage
• V4A stainless steel coupling nut and EPDM seal for IP65 up to IP69 protection
• Gold-plated CuSn contacts for a reliable connection
• Wide temperature range from -40 C to +105 C

Technical data

• Model: sensor cable, open/M12 socket 5-pin F&B
• Design: sensor cable, TPE, grey
• Coding: A-coded
• Cable length: 5 m
• Connection to luminaire: M12 socket connector, straight, EPDM seal, V4A coupling nut
• Cable ends: open ends, 5 leads / M12 socket, straight
• Number of pins: 5
• Rated voltage: 250V
• Current load per pin: 4000 mA
• Operating temperature: -40 C to +105 C
• Protection rating (mounted): IP65, IP67, IP68, IP69
• Cable material: TPE
• Coupling nut material: stainless steel, V4A
• Seal material: EPDM
• Contact material: metal, CuSn, gold-plated
• Standards: IEC 61076-2-101
• Weight: 200 g
• Certifications: CE
• Special feature: food and beverage suitable, FDA-approved
• Made in: Germany

Applications

Connecting LED2WORK 24V DC luminaires with an M12-A connection in the food and beverage industry, in particular RGB and RGB-W luminaires whose signal function uses the fifth core.
