Semi-automatic device for inserting pre-magazined solder lugs. Triggered by plunger or foot switch, one-second cycle, complete with magazine, insertion head, cover and insertion needles.
Solder Lug Insertion Device A 040 with Double Tongue
A1-ESD
Original product
Net price (excl. VAT)
€6,554.00
Item
M-040-33018-2
Manufacturer no.
M-040-33018-2
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.M-040-33018-2
EAN4057989330198
ConditionNew
Article
M-040-33018-2
Frequently Bought Together
-
This Item:
€6,554.00
-
Display PocketMax Electric, 9 Units Order No. 45296 - Wiha 45323
€275.39
-
C.K T6104A. Replacement nozzle for ESD Desoldering pump
€3.32
Total price
The type A 040 device inserts pre-magazined solder lugs at a one-second cycle. The insertion process is triggered by a plunger or a foot switch. It processes all commercial solder lugs lined up on a wire or adhesive strip. By changing the insertion head and the magazine, solder lugs of other dimensions and shapes can also be processed.
Technical data
- Dimensions: 320 x 600 x 600 mm
- Weight: approx. 20 kg
- Power supply: 230 V / 50 Hz
- Working pressure: 3.5 - 4 bar
- Magazine: 300 - 400 solder lugs (threaded)
- Performance: one-second cycle
Scope of delivery
- Machine, magazine, insertion head, cover, insertion needles
Options
Also available on request with tape feeder A 040B or with bowl feeder for loose components A 040R.
| Weight | 20.000000 |
|---|---|
| Manufacturer | A1-ESD |
| Manufacturer Nr. | M-040-33018-2 |
| EAN | 4057989330198 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Height | 600 mm |
| Width | 600 mm |
| Depth | 320 mm |
