Cir-Kit Advanced Version, Circuit Repair Kit - PACE 6993-0077

Name: Cir-Kit Advanced Version, Circuit Repair Kit - PACE 6993-0077
Brand: PACE
SKU: PC-6993-0077
Price: 327.94 EUR
Availability: InStock

PACE ✓ Original product Brand new Made in United States

Advanced version of the PACE Cir-Kit for repairing damaged traces, pads and DIP pads on circuit boards. It includes four frame types with replacement patterns plus eyelets, funnelets and setting tools.

Net

€327.94

excl. VAT

Item PC-6993-0077

Manufacturer no. 6993-0077

Question about this item

Datasheet (PDF) 2 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Lifted pads, broken traces or damaged DIP pads do not have to turn an assembly into scrap. The Cir-Kit Advanced Version supplies four frames with ready-made replacement patterns, together with eyelets, funnelets and a setting tool for plated through-holes.

Benefits

Track pad, straight run, DIP pad and variety frames cover pads, straight runs, DIP patterns and angles or tees
Eyelets and funnelets, 25 of each type, to restore plated through-holes
Upper and lower setting tools with guide and base for clean setting
Abrasive stick to expose bare copper before bonding

Specifications

Applications

Repair of traces and pads on through-hole and mixed technology boards
Restoration of plated through-holes
Rework in repair shops and rework departments

Technical data

Manufacturer part number	6993-0077
Type	Cir-Kit, Advanced Version (non-ThermoBond)
Frames	Track Pad Frame 1200-0070, Straight Run Frame 1200-0074, Dip Pad Frame 1200-0072, Variety Frame 1200-0073
Eyelets and funnelets	1347-0007, -0009, -0010, -0013, -0016, -0051, -0053, 25 of each
Tools	Upper Setting Tool 6000-0051, Setting Tool Guide 6000-0054, Lower Setting Tool 1132-0017, Support Tool Base 1321-0054
Accessories	Abrasive Stick 1129-0014
Sales unit	1 piece (kit)
Weight	0.05 kg
Manufacturer	PACE
Manufacturer Nr.	6993-0077
HS-Code	85159080
GPSR manufacturer information	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
