ADS200 AccuDrive Soldering Station with TD-200 and Standard Stand - PACE 8007-0580

On a production line the tip has to recover quickly, even on ground planes. The ADS200 senses the load instantly and delivers up to 120 W on demand, so joints reflow at the lowest temperature needed, without calibration and without changing cartridges for other temperatures.

Benefits

• 193 to 454 °C set with arrow keys, temperature accuracy to J-STD-001.
• TD-200 with Cool Touch aluminium handle and only 48 mm tip-to-grip, suited to work under a magnifier or microscope.
• Blue Series cartridges change in 2 seconds without switching the unit off.
• ESD safe: tip-to-ground resistance of 2 Ohms or less, ANSI/ESD S20.20.

Specifications

Applications

• Hand soldering in series production
• Micro-soldering from 0201 up to D-Pak
• Mobile device and electronics repair
