Rack-and-pinion Z-axis focusing module with coarse and fine motion, made for XY-travel stands. Sets exact focus when working with add-on macro lenses.
Rack-and-Pinion Focusing Module for Travel Stands, Coarse/Fine - Inspectis HD-172
INSPECTIS
Original product
Net price (excl. VAT)
€726.28
Item
HD-172
Manufacturer no.
HD-172
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.HD-172
Country of originSweden
Customs tariff number84798997
ConditionNew
Article
HD-172
Frequently Bought Together
-
This Item:
€726.28
-
Interchangeable 90-degree side-view probe small size (spare part) - Inspectis BGA-007
€2,246.75
-
Vision ECO2504. EVO CAM II digital microscope ECO2504 with multi-axis column Standand focus module
€12,591.47
Total price
The HD-172 adds coarse and fine rack-and-pinion focusing to an XY-travel stand, so you set exact focus while scanning, including when +3, +5 or +10 macro lenses are fitted. It mounts on the travel-stand carriage and carries the camera head.
Key benefits
- Combined coarse and fine motion for fast travel and exact focus.
- Made for XY-travel stands and their carriage.
- Supports focusing with +3, +5 and +10 macro lenses.
- 2.0 kg module for controlled Z-adjustment while scanning.
Technical specifications
| Type | Rack-and-pinion focusing module |
| Motion | Coarse and fine |
| For | XY-travel stands |
| Lens support | Macro +3, +5, +10 |
| Weight | 2 kg |
| Dimensions | 25 x 23 x 13 cm |
| Country of origin | Sweden |
| Customs/HS code | 84798997 |
Typical applications
Setting precise focus on XY-travel stands, especially when macro lenses change the working distance.
Compatibility and notes
For Inspectis XY-travel stands. Macro lenses +3, +5, +10 supported. Made in Sweden.
| Manufacturer Nr. | HD-172 |
|---|---|
| Manufacturer | Inspectis |
| Country of Manufacture | Sweden |
| Weight | 2.000000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
