Drawer unit 53/66-9 with base, 5 drawers 3x100/2x150 mm - Treston 5366209-07
Treston drawer unit 53/66-9 on a base with five lockable drawers (3x100, 2x150 mm), each fully opening and rated for up to 60 kg. The unit carries 480 kg in total and measures 530x640x800 mm. Use it free-standing in storage or as a load-bearing leg under a heavy-duty workbench.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Treston drawer unit 53/66-9 keeps tools, spare parts and materials within reach at the workstation and safely locked away. Three 100 mm drawers for tools and small parts are combined with two 150 mm drawers for larger components and devices. Every drawer opens 100 % and carries up to 60 kg, the whole unit up to 480 kg.
Key features
- 5 lockable drawers configured as 3x100 and 2x150 mm
- 100 % drawer opening, so the rear of each drawer is easy to reach
- 60 kg per drawer and 480 kg total load
- Base instead of castors, the unit stands firm and can serve as a leg for a heavy-duty workbench
- Divider sets for interior organisation available as accessories
- 10-year manufacturer warranty
Technical data
| Product code | 5366209-07 |
|---|---|
| Series | Drawer unit 53, model 53/66-9 |
| Width x depth | 530 x 640 mm |
| Height | 800 mm |
| Drawers (pcs x height) | 3x100, 2x150 mm |
| Internal drawer dimensions (WxDxH) | 460 x 612 x 85/235 mm |
| Drawer opening | 100 % |
| Load per drawer | max. 60 kg |
| Drawer unit load | max. 480 kg |
| Frame | Base (plinth) |
| Material | Epoxy powder-coated steel |
| Colour | Frame grey, drawers blue |
| ESD | No |
| Origin | Finland |
| Warranty | 10 years |
| Manufacturer | Treston |
| Manufacturer Nr. | 5366209-07 |
| EAN | 6416763098743 |
| HS-Code | 94032080 |
| GPSR manufacturer information | Treston Deutschland GmbH, Friedrich-Ebert-Damm 143, DE-22047 Hamburg |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Finland |
| Sales unit | 1 |
| Width | 530 |
| Depth | 640 |
| ESD version | TEC |
Typical locations are workshops, maintenance, assembly and stores. Under a heavy-duty workbench the unit replaces a leg and adds storage space beneath the work surface.
