Stacking bin rack for bins 1940, 1950, 3040, 3050, 990x600x1670 mm, 350 kg - Treston BR-4050
Rack in powder-coated steel with six fixed levels inclined forward at 20 degrees for Treston stacking bins 1940, 1950, 3040, 3050. Each level carries 50 kg and the complete rack 350 kg. Built for stores and parts issue points with frequent access to small parts, bins are ordered separately.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
On the BR-4050 rack, stacking bins sit at a 20-degree angle. Contents are visible from the front and quick to pick, which shortens every reach for frequently used small parts. The epoxy powder-coated steel frame carries six fixed levels rated at 50 kg each.
Key features
- 6 fixed levels, inclined forward at 20 degrees
- Load capacity 50 kg per level, 350 kg per rack
- Epoxy powder-coated steel frame, light grey RAL 7035
- Stacking bins not included, order separately
Bin capacity
- Stacking bin 1940: max. 5 per rail, 30 per stand
- Stacking bin 1950: max. 5 per rail, 30 per stand
- Stacking bin 3040: max. 3 per rail, 18 per stand
- Stacking bin 3050: max. 3 per rail, 18 per stand
Technical data
| Product code | BR-4050 |
|---|---|
| External size WxDxH | 990x600x1670 mm |
| Levels | 6, fixed, 20-degree incline |
| Load capacity | 50 kg per level, 350 kg total |
| Material | Epoxy powder-coated steel |
| Colour | Light grey, RAL 7035 |
| Compatible with | Stacking bins 1940, 1950, 3040, 3050 |
| ESD | No |
| Warranty | 10 years |
| Weight | 22.5 kg |
| Manufacturer | Treston |
| Manufacturer Nr. | BR-4050 |
| EAN | 6416763039012 |
| HS-Code | 94032080 |
| GPSR manufacturer information | Treston Deutschland GmbH, Friedrich-Ebert-Damm 143, DE-22047 Hamburg, www.treston.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Finland |
| ESD version | TEC |
| ESD equipment | Nein |
Suited to stores, workshops and assembly areas where small parts are picked many times a day.
