LED surface-mounted luminaire OBLO.fit OBA 1000/830/D/WS, Ø 300 mm, 1200 lm, DALI - Waldmann 00800125

Where lighting is switched centrally, dimmed or controlled by presence detectors, even a small ceiling luminaire needs a bus interface. This 300 mm OBLO.fit has one: DALI with 1x load, plus 1200 lm at 11 W in warm white 3000 K light. The opal acrylic cover gives an evenly glowing surface.

Benefits

• DALI interface (DALI load 1x) for integration into lighting management and building control.
• 1200 lm at 11 W from one LED module with built-in converter.
• White opal acrylic (PMMA) cover, no visible light points.
• White sheet metal housing, IP40, protection class I.
• Same appearance as the switchable variant, so mixed installations look uniform.

Applications

• Corridors and circulation areas with presence-based control
• Meeting and treatment rooms with dimming scenes
• Administrative buildings with DALI lighting management

Installation and accessories

• Ceiling mounting, direct connection 220-240 V plus DALI control line
• Control via DALI controller or presence detector with DALI output
• Larger 460 mm DALI version in the same series
