LED high bay luminaire ACANEO HIAL 20000/840/W/EA, 140 W, 22,000 lm, 88° wide beam, switchable - Waldmann 113539000-00734332

Where a hall needs even lighting without bright spots and dark zones, the ACANEO HIAL 20000/840/W/EA provides approx. 22,000 lm at approx. 140 W. Its luminous efficacy of approx. 157 lm/W keeps energy demand low, even in multi-shift operation. The 88° wide-beam optic spreads the light across the area and suits open zones and lower mounting heights. It is simply switched externally, no control line required.

Benefits

• Simple external switching, no control wiring or programming
• 88° wide beam optic: uniform lighting of large, open hall areas
• 4000 K neutral white light, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for consistent light throughout the hall
• IP65, protection class I and operation at ambient temperatures from -30 °C to 50 °C, also for unheated halls and cold areas

Applications

• Production halls and assembly areas
• Open storage and logistics areas
• Order picking and shipping areas

Installation and accessories

• Fastening available separately: ceiling bracket, 1-point suspension, trapezoidal hanger or wire rope with wire rope holder
• Mains connection via built-in plug RST 25i3, junction box RST 25i3 and safety glass available as accessories
