LED workplace-system luminaire WLA 1100/850/D, 449 mm, DALI dimmable, left-hand mounting - Waldmann 113879000-00754398

Narrow inspection and assembly stations leave little room for a long luminaire. The WLA 1100/850/D puts 1150 lm from 15 W straight onto the work surface over a length of 449 mm, in neutral white at approx. 5000 K with CRI ≥ 80. The rocker switch on the luminaire dims it continuously, and DALI integrates it into a lighting control system. This version is designed for left-hand mounting.

Benefits

• 1150 lm at 15 W (approx. 76 lm/W), 5000 K neutral white and CRI ≥ 80 for visual inspection at the workbench
• Prism aperture with structured cover limits glare, 85° beam angle, approx. 100 % direct light
• Continuously dimmable via rocker switch, DALI interface for light management
• Left-hand mounting version, a counterpart WLA 1100/850/D is available for right-hand mounting
• Housing of colourless anodised aluminium and plastic, dusty grey side parts, IP20, protection class I

Applications

• Inspection and visual check stations
• Compact assembly and manual workstations
• Narrow workbenches

Installation and accessories

• Fastening via luminaire bracket set (accessory, dusty grey, also with 90° angle) or the T-slots (8 mm)
• Mains connection via built-in GST 18i3F REV plug, matching 3 m connection cable with CEE 7/7 Schuko plug to GST18i3 (accessory)
